MODEL

FTCP-600BE

FTCP-900BE

FTCP-1100BE

FTCP-1300BE

WORKING WIDTH (inch/mm)

24/610

36/915

43/1100

52/1320

WORKING THICKNESS (inch/mm)

5/127

MAIN MOTOR STD/MAX (HP)

10,15/15,20

15,20/20,25

20,25/25,25

20,25/30,20

FEED MOTOR (HP)

2

3

HOIST MOTOR (HP)

12

SANDING BELT SIZE (inch)

25*75

37*75

43*75

52*75

SANDING BELT SPEED (m/sec/fpm)

17/3400

FEED SPEED (m/min/fpm)

4-16/13-54

DUST COLLECTOR MOUTH (ØDia*holes)

Ø100mm(Ø4")*4

Ø150mm(Ø4")*4

NET WEIGHT (kgs)

1800

3000

3500

3700

GROSS WEIGHT(kgs)

2100

3300

3900

4100

PACKING SIZE(L*W*H) (inch)

69*78*83

72*78*83

76*82*83

85*82*83
